CAN I/O for Control Cabinets- SNAP version

Pricing includes 10% GST and Local Economical Freight

Part No: Select variant
Brand : Microcontrol GmbH

Signal Types

  • 1-channel to 8-channel modules
  • Analogue inputs +/- 10 V, 0(4)…20 mA
  • Analogue outputs +/- 10 V, 0…20 mA
  • Analogue inputs strain gauge
  • Temperature acquisition thermocouples
  • Temperature acquisition Pt100,Pt200, Pt500, Pt1000
  • Digital in- or outputs
  • Digital counter input up to 500 kHz
  • Digital PWM outputs up to 1.5 A per output

Only Galvanically isolated option is available, if you need non-galvanic isolation, please contact us.

This product is currently out of stock and unavailable.

SKU: N/A Category:

Description

The modules of the SNAP series integrate the advantages and efficiency of digital CAN networks into control cabinets. With its 22.5 mm SNAP casing the modules are ideally suitable for TS35 tophat rail mounting and feature space-saving installation, low weight and a functional structure.

The modules are equipped with a high-speed CAN interface to connect sensors and actuators with a digital CAN network. The CAN interface supports CAN 2.0A as well as CAN 2.0B, which serve the layer-7 protocols CANopen, J1939 and a variety of manufacturer-specific variants (RAW CAN).

Usage:
Control cabinets
Operating temperatures -40…+85 °C
Power supply voltage 9…36 V DC
Tophat rail casing 22.5 mm
DIN rail mouting TS35
IP20 ranked
Status indication by LED
CE certified

Additional information

Choose variant

µCAN.6.ai-SNAP (6-channel analogue input module), µCAN.8.ti-SNAP (8-channel analogue input Temperature acquisition), µCAN.4.ao-SNAP (4-channel analogue output Current / voltage), µCAN.8.dio-SNAP (8-channel Digital input or output), µCAN.8.pwm-SNAP (8-channel digital Pulse width modulation output), µCAN.4.ci-SNAP (4-channel digital Counter input)
