TSMaster is a powerful engineering software platform for CAN, CAN FD, LIN, J1939 and FlexRay analysis, simulation, diagnostics, calibration and testing. Develop test systems, analyse bus traffic, simulate ECUs, log and replay data, perform UDS diagnostics and automate testing from a single platform.
| Software | TSMaster |
|---|---|
| Supported Networks | CAN, CAN FD, LIN, J1939, FlexRay and Ethernet* |
| Bus Analysis | Real-time traffic monitoring and analysis |
| Simulation | CAN/CAN FD RBS, LIN RBS, J1939 simulation, FlexRay simulation |
| Logging | Data logging and playback |
| Diagnostics | UDS diagnostics and Flash Bootloader functions (PRO) |
| Calibration | CCP/XCP calibration with A2L support (PRO) |
| Scripting | C Script and Python |
| Test Development | Custom panels, test processes, test logic and automated reporting |
| Co-Simulation | MATLAB Simulink and CarSim soft real-time HIL |
| Development APIs | Available for software and hardware integration |
| Trial | 30-day free trial available |
| Operating System | Windows 7 SP1 or later, including Windows 10 and Windows 11 |
*Network functionality depends on the selected hardware and TSMaster configuration.
