The TOSUN TC1017 is a high-density 8-channel CAN FD to USB interface designed for multi-network CAN analysis, simulation, data acquisition and automated testing.
| Model | TC1017 |
|---|---|
| CAN Channels | 8 × CAN FD |
| PC Interface | USB 2.0 |
| CAN Interface | DB37 with DB9 breakout cable |
| CAN | CAN 2.0A/B, 125 Kbps–1 Mbps |
| CAN FD | ISO and non-ISO CAN FD, 125 Kbps–8 Mbps |
| Channel Buffer | Up to 700 CAN FD frames per channel at 64 bytes |
| Timestamp | 1 μs hardware timestamp |
| Termination | Built-in 120 Ω, software configurable |
| Transmit Rate | Up to 17,000 frames/second |
| Receive Rate | Up to 17,000 frames/second |
| Isolation | DC 2500 V CAN channel isolation |
| Power Supply | DC 7–18 V |
| Operating Temperature | -40°C to 85°C |
| Housing | Aluminium |
| Dimensions | 106 × 84 × 32 mm |
